HLG-80H-24A Mean Well Power Supply 24V 80W
Model / reference: HLG-80H-24A
Category: MEAN WELL Power Supply
Official datasheet for HLG-80H-24A
Use the 24V output column together with the A-suffix option. The A version is IP65 and uses built-in output-adjustment controls; the B version has a different dimming interface.
Open MEAN WELL HLG-80H datasheet (PDF) — opens in a new tab
Manufacturer document, revision 2026-02-04. This series file covers multiple output versions; check the full part number before ordering.
Selection note: Include the complete HLG-80H-24A part number, load, destination and control requirements in your inquiry so the supplied suffix and installation conditions can be checked.
Request project documents & review
Please include the required version, quantity and destination country.
Request a quote for this model
HLG-80H-24A Mean Well Power Supply 24V 80W
For HLG-80H-24A, confirm the complete model suffix, 24V load and adjustment/control requirements. Request approval before substituting another suffix.
Quote this model & matching partsWhatsApp about this model
What should I include in my inquiry?
- Include the full MEAN WELL part number and suffix, quantity and destination country.
- For selection help, send the LED load, voltage, run lengths, mains input and intended control/dimming system.
- Confirm the model dimensions, installation environment, available documentation and any required cables or connectors.
Ask us to confirm compatibility, model documents, availability and lead time in the quotation.
Detail Description
|
HLG-80H-24A Mean Well Power Supply 24V 80W |
|||||||
|
Model: |
HLG-80H-24A |
||||||
|
DC VOLTAGE: |
24V |
||||||
|
Rated Current: |
3.4A |
||||||
|
Input voltage: |
90~305VAC |
||||||
|
Rated Power: |
81.6W |
||||||
|
Frequency Range: |
47~63Hz |
||||||
|
Leakage Current: |
<0.75mA/277VAC |
||||||
|
Efficiency: |
90% |
||||||
|
Dimension: |
195.6*61.5*38.8mm(L*W*H) |
||||||
Detailed description of HLG-80H-24A Mean Well Power Supply 24V 80W:
1)Constant Voltage + Constant Current mode output
2)Built-in active PFC function
3)HLG-80H-24A: built-in voltage and current adjustment (A type, IP65). Ask us to review a B or AB version if your project requires a 3-in-1 dimming input.
4)7 years warranty
5)Typical lifetime> 62000 hours
