Single color led controller RF 12-24V 8A
Model / reference: YT-CON-RF-12-24V-8A-1
Category: Single Color Led Controller
Please include the required version, quantity and destination country.
Request a quote for this model
Single color led controller RF 12-24V 8A
Quote this model & matching partsWhatsApp about this model
What should I include in my inquiry?
- Send the accessory model, quantity and the exact LED strip, Neon Flex or power supply it must connect to.
- Include dimensions, pin count/polarity, voltage/current and the installation environment as applicable.
- Attach a photo or drawing and list any other parts to include in the same quotation.
Ask us to confirm compatibility, model documents, availability and lead time in the quotation.
Detail Description
|
Single color led controller RF 12-24V 8A |
|||||||
|
Model: |
YT-CON-RF-12-24V-8A-1 |
||||||
|
Input voltage: |
DC12~24V |
||||||
|
Single max output current: |
8A |
||||||
|
Max output watts: |
60W(for 5V) 96W(for 12V) 192W(for 24V) |
||||||
|
Output: |
1 Channel |
||||||
|
External dimension: |
L115*W56*H34mm |
||||||
|
Packing size: |
L121*W85*H46mm |
||||||
|
Net weight: |
110g |
||||||
|
Gross weight: |
130g |
||||||
|
Static power consumption: |
<1W |
||||||
Detailed description of Single color led controller RF 12-24V 8A:
1)RF Single color LED Dimmer is dedicated to adjust the brightness of LED lights,which adopted the most advanced PWM(Pulse-Width Modulation) digital brightness-adjusting technology at present;
2)Users can use the RF wireless remote control to control the brightness in the distance;
3)It is suitable for LED Strip and other low-power constant voltage LED products;
4)It can extend life tenure of LED and energy-saving.
